1. The large sewing area of the HighTex MLK300 allows it to be a versatile electronic pattern industrial sewing machine for use in many different sections of the clothing, leather and textile industry;

2. This automatic pattern sewing machine stands hightest quality in China, better than any other Chinese CNC programmable pattern sewing machine;

3. Due to its affordable price (but not the cheapest machine), it is an excellent replacement of Mitsubishi electronically controlled pattern sewing machine, Juki programmable pattern sewing machine, Juki and Brother BAS programmable electronic pattern sewer;

4. Top quality parts guarantee high performance and long working life, including Japanese rotary hook (Koban or Hirose) and SMC pneumatic system;

5. There are no limitation of custom items this machine can sew provided the sewing pattern stays within its sewing field and the material does not exceed certain thickness levels;

6. This CNC programmable sewing machine with automatic thread trimmer and automatic lubrication system, easy to operate and maintain, does not require skilled workers;

7. Each machine supplies with comprehensive spare parts package that allow you to service, maintain and repair the machine for long time without the need to buy spare parts;

8. We offer you not just a machine in a box, but will custom clamp /jig for your tasks, pre-program, thoroughly test the machine before delivery.

single color embroidery, functional or decorative stitching on jeans, clothes, bags, shoes, webbing strap, lanyards, vehicle harnesses, pet harnesses, dog harnesses, dog collars & leashes, lashing straps, upholstered walls, luggage, leather jackets, and attaching label, widely used for many different industries.

Max. Sewing Speed: 2500 rpm

Hook Type: 2 times large rotary hook

Sewing Area: 300x200mm (standard), 600x400mm

Needle System: DPX17 #18

Max. Thread size: Metric #15 (=V207, T-210, 630dx3)

Optimal sewing thickness: 2-5mm of thick leather, webbing and clothing

Bobbin size: Outside Dia. 25mm, Height 11mm

Stitch Length: 0.1~12.7mm

Work Holder Lift: 32mm

NeedleBar Stroke: 41.2mm

Presser Foot Lift: 18mm

Presser foot stroke: 4 mm to 10 mm

Max. QTY of Patterns: 10000 patterns

Needle cooler: Cold air

Pattern Storage: Internal & USB

Max. Number of Stitches: 8000 per pattern

Drive Motor: Limi-Servo (450 Watts)

Air pressure: 0.6 MPa

Power: 200-240 Volt 1 or 3 Phase

Thread trimmer system: Horizontal engagement with fixed knife and movable knife

Package (plywood case):1200x1230x 1300 MM, G.W: 208KGS

Video of sewing webbing, leather

Video for sewing shoe upper

Video of sewing label

Sewing Japanese Kendo Armour
